Technical Spesification:
| Assays | PT | |
| aPTT | ||
| FIB | ||
| Thrombin Time | ||
| PT/FIB | ||
| Batroxobin Time | ||
| Protein C & S | ||
| Ecarin Test Factors (II-XII) | ||
| Factor V Leiden | ||
| PiCT (Prothrombinase induced Clotting Test) | ||
| D-Dimer | ||
| CRP (C-Reactive Protein) | ||
| ATIII | ||
| TDT (Thrombin Dynamics Test) | ||
| TAFI (Thrombin Activatable Fibrinolysis Inhibitor) | ||
| Measuring Principle | Photometric; with magnetic stirrers to homogenize the test mixture and increase the sensitivity | |
| 2 channel LED photometer (405/570/740nm) with 2 reference channels | ||
| Measuring Unit | Controlled at 37.40C ± 0.40C | |
| 2-measuring channels and reference channels | ||
| Test Volume | 32 cuvette ring rotor for single use | |
| Total min. 150µL; max. 300µL | ||
| Sample/Reagent Platform | 2×11 sample positions, 15 reagent positions (3x15ml, 12x5ml), 2 stirred, 3 STAT positions, 1 wash station | |
| Sampling | Capacitive pipetting device, moves in 3 directions | |
| Pipettor heated at 370C | ||
| Dilutor, 2-250µg (precise in 1µg steps) | ||
| Display | Touch sensitive color display, On-board graphic user software | |
| Interfaces | 2x RS232C, 2x USB, LAN & ChipCARDTM reader | |
| External Connection | External USB printer connectable, External Barcode Scanner connectable, PC communication | |
| Dimensions | W x D x H : 78 x 58 x 50 cm | |
| Weight: 25.0 Kg | ||
| Power Consumption | 110/240V, 50/60 Hz |
